| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-900-18 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Rang: | 806~960MHz | Gain: | 18dBi |
|---|---|---|---|
| Polarization: | Vertical | Type: | Extenal |
| Color: | Gray, White, Balck, Etc. | Connector: | N |
| High Light: | antenna,antennas for communications,gsm antenna |
||
Panel antenna 900MHz 18dBi:
806~960MHz
18dBi
Manufacturer produce
800-900MHZ Mobile System
Panel antenna 900MHz 18dBi:
Feature :
High Gain
H or V Polarization
Full day for working
Durable, corrosion resistance
Optimized dimension
Application :
GSM/CDMA/PCS/3G/WLAN System
Sector signal coverage
Base station &Repeater station system
Wireless telecommunication & Data transmission system
|
AMXP-900-18 Electric Specifications |
|
|
Frequency rang |
806-960 |
|
Polarization |
Vertical |
|
Gain(DBi) |
18 |
|
Beamwidth(0°) |
H:65 V:60 |
|
F/B ratio(DB) |
≥25 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Max power(W) |
400 |
|
Mechanical Specifications |
|
|
Connector model |
N Female |
|
antenna size (mm) |
1300*280*80 |
|
Packing size(mm) |
|
|
Antenna weight (kg) |
8.3 |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt(°) |
0~10 |
|
Working Temperatu(°c) |
-40~60 |
|
Rated Wind Velocit(m/s) |
60 |
|
Pole diamete(mm) |
50~75 |
