| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXY-8090-17 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 890-960 | Bandwidth（MHz）: | 70 |
|---|---|---|---|
| Gain（dBi）: | 17 | Element: | 16 |
| Half-power Beam Width（°）: | H：32 V：30 | Polarization: | Horizontal Or Vertical |
| Lightning Protection: | DC Ground | Input Connector Type: | TNC Male Or Requested |
| Clamp: | U-shape |
890-960MHz Directional Yagi Antenna
AMXY-8090-17
Feature:
High gain
Aluminum alloy framework
Full day working
Optimized dimension
Mounting way can be Vertical or Horizontal
Application:
CDMA, GSM system
Point-to-point,point-to-multipoint system
Wireless bridging,client terminal antennas
|
AMXY-8090-17 Electrical Specifications |
|
|
Frequency range(MHz) |
890-960 |
|
Bandwidth(MHz) |
70 |
|
Gain(dBi) |
17 |
|
Element |
16 |
|
Half-power beam width(°) |
H:32 V:30 |
|
Front-to-back ratio(dB) |
≥16 |
|
VSWR |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Horizontal or Vertical |
|
Maximum input power(W) |
100 |
|
Lightning protection |
DC Ground |
|
Input connector type |
TNC Male or Requested |
|
Mechanical Specifications |
|
|
Dimensions(mm) |
1160*190*54 |
|
Cable length(m) |
0.3 |
|
Antenna weight(kg) |
0.6 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Clamp |
U-shape |
|
Mounting hardware(mm) |
Φ35～Φ50 |
