| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXF-900-8 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Type: | Extenal | Frequency: | 806-960 MHz |
|---|---|---|---|
| Gain: | 8dBi | Dimension: | 20*1200mm |
| Weight: | 700g | Cable Lengh: | 1.3m |
| Conector: | N Male | ||
| High Light: | fiberglass antenna,antenna for 3g,3g antenna outdoor |
||
CDMA signal amplifier antenna:
CDMA800/GSM900 mobile system
Direct manufacturer price
6-12dBi
CDMA signal amplifier antenna:
Good appearance
Durable, corrosion resistance
Full day for working
waterproof
Optimized dimension
High Gain
Lower VSWR
Strongly Anti-interference
CDMA800/GSM900 mobile system
Application:
Point to Multipoint system
Wireless data transmission system
|
Model NO |
AMXF-900-8 |
|
Electric Spec |
|
|
Frequency rang-MHz |
806~960 |
|
Bandwidth -MHz |
154 |
|
Gain -dBi |
8 |
|
beam width -° |
H:360 V:17 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Vertical |
|
Max power -W |
100 |
|
Lightning protection |
DC ground |
|
Connector model |
N Female |
|
Mechanical Specification |
|
|
Size -mm |
Φ25*900 |
|
Antenna weight-kg |
0.8 |
|
Working Temperature -°c |
-40~60 |
|
Rated Wind Velocity-m/s |
60 |
|
Radome color |
gray |
|
Mounting way |
hold in the pole |
