| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-2327S-D14L30 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 2300～2700 | Polarization: | ±45° |
|---|---|---|---|
| Gain（dBi）: | 2×14 | VSWR: | ≤1.5 |
| Maximum Input Power（W）: | 200 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2xRP-SMA Male Or Requested |
2.3-2.7G Mimo Antenna
AMXW-2327S-D14L30
Feature:
High gain
Full day working
Optimized dimension
Dual polarization
Application:
2.3/2.7 GHz WLAN system
2.3/2.7 GHz ISM band
Public wireless hot spot coverage
Wi-Fi system
|
AMXW-2327S-D14L30 Electrical Specifications |
|
|
Frequency range(MHz) |
2300～2700 |
|
Polarization |
±45° |
|
Gain(dBi) |
2×14 |
|
Half-power beam width(°) |
H:30 V :30 |
|
Front-to-back ratio(dB) |
≥27 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Isolation between ports |
≥28dB |
|
Cross-polar ratio |
≥15dB@0º ≥10dB@+/-60º |
|
Sidelobe suppression for first sidelobe above horizon |
15 dB |
|
Maximum input power(W) |
200 |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
2xRP-SMA male or Requested |
|
Dimensions-mm (Height/Width/Depth) |
225*195*47 |
|
Antenna weight (kg) |
0.8 |
|
Radome material |
ABS |
|
Radome color |
White |
|
Mechanical tilt(°) |
0～10 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Mounting hardware(mm) |
￠35～￠50 |
