| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-2425VH-D18L65 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 2400～2500 | Polarization: | Vertical And Horizontal |
|---|---|---|---|
| Gain（dBi）: | 2×17.5 | Half-power Beam Width（°）: | H:65 V:7 |
| VSWR: | ≤1.5 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2-N Female | ||
| High Light: | wifi antenna,horizontal polarization panel antenna,wifi outdoor antenna |
||
2.4 GHz WiFi Panel Antenna
Factory price
All weather operation
Heavy-duty waterproof radome
Included mounting brackets
2400-2500MHz Directional Panel Antenna
AMXP-2425VH-D18L65
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
2.4 GHz WLAN system
2.4 GHz ISM band
Public wireless hot spot coverage
Wi-Fi system
AMXP-2425VH-D18L65 Electrical Specifications | |
Frequency range(MHz) | 2400～2500 |
Polarization | Vertical and Horizontal |
Gain(dBi) | 2×17.5 |
half-power beam width(°) | H:65 V:7 |
Front-to-back ratio(dB) | ≥25 |
Input Impedance(Ω) | 50 |
VSWR | ≤1.5 |
Isolation between ports | ≥28dB |
Cross-polar ratio | ≥15dB@0º ≥10dB@+/-60º |
Sidelobe suppression for first sidelobe above horizon | 15 dB |
Maximum input power(W) | 200 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 2-N Female |
Dimensions-mm (Height/Width/Depth) | 1000*175*80 |
Packing size(mm) | 1080*200*150 |
Antenna weight (kg) | 6.5 |
Radome material | UPVC |
Radome color | Gray |
Mechanical tilt(°) | 0～10 |
Operating temperature(°c) | -40～60 |
Rated Wind Velocity(m/s) | 60 |
Mounting hardware(mm) | ￠35～￠75 |
