698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna

698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna

    • 698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna
    • 698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna
    • 698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna
    • 698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna
    • 698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna
  • 698-960MHz 2x13dBi Directional Panel Antenna 3g antenna gsm antenna lte antenna

    Product Details:

    Place of Origin: Shenzhen, China.
    Brand Name: AMEISON
    Certification: RoHS and REACH Compliant by Exemption
    Model Number: AMXP-7090S-D13L120

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs per item
    Price: FOB SHENZHEN
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging)
    Delivery Time: 10 days
    Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
    Supply Ability: 80,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 698~960 Polarization: ±45º
    Gain(dBi): 2×13 Half-power Beam Width(°): H:120 V:15
    VSWR: ≤1.5 Lightning Protection: DC Ground
    Input Connector Type: 2-N Female Mounting Hardware(mm): ¢35~¢90

    698-960MHz Directional Panel Antenna

    AMXP-7090S-D13L120

    Feature:

    High gain

    Full day working

    Optimized dimension

    Dual polarization

    Application:

    LTE,CDMA,GSM system

    Wireless communication and data transmission system

    AMXP-7090S-D13L120

    Electrical Specifications

    Frequency range(MHz)

    698~960

    Polarization

    ±45º

    Gain(dBi)

    2×13

    Half-power beam width(°)

    H:120 V:15

    Front-to-back ratio(dB)

    ≥18

    Input Impedance(Ω)

    50

    VSWR

    ≤1.5

    Isolation between ports

    ≥28dB

    Cross-polar ratio

    ≥15dB@0º ≥10dB@+/-60º

    Sidelobe suppression for first sidelobe above horizon

    15 dB

    Maximum input power(W)

    400

    Lightning protection

    DC Ground

    Mechanical Specifications

    Input connector type

    2-N Female

    Dimensions-mm (Height/Width/Depth)

    1360*280*125

    Packing size(mm)

    1410*320*210

    Antenna weight (kg)

    8.9

    Radome material

    UPVC

    Radome color

    Gray

    Mechanical tilt(°)

    0~10

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Mounting hardware(mm)

    ¢35~¢90
