| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXF-9092-10 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 902-928 | Bandwidth（MHz）: | 26 |
|---|---|---|---|
| Gain（dBi）: | 10 | VSWR: | ≤1.5 |
| Polarization: | Vertical | Lightning Protection: | DC Ground |
| Input Connector Type: | N Female Or Requested | Mounting Way: | Pole-holding |
| Highlight: | omni antenna,gsm antenna,rfid antenna |
||
900MHz Omni Fiberglass Antenna
Factory price
Lightweight fiberglass radome
Provided wifh dual u-bolt mast mounting kit
902-928MHz Omnidirectional Fiberglass Antenna
AMXF-9092-10
Feature:
Exquisite appearance
Good impact resistance,waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain
Low VSWR
Strong anti-interference ability
Application:
902-928MHz frequency band
Radio Frequency Identification system
Point-to-multipoint system
|
AMXF-9092-10 Electrical Specifications |
|
|
Frequency range(MHz) |
902-928 |
|
Bandwidth(MHz) |
26 |
|
Gain(dBi) |
10 |
|
Half-power beam width(°) |
H:360 V:9 |
|
VSWR |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical |
|
Maximum input power(W) |
100 |
|
Lightning protection |
DC Ground |
|
Input connector type |
N Female or Requested |
|
Mechanical Specifications |
|
|
Dimensions (mm) |
Φ20*1570 |
|
Antenna weight(kg) |
0.65 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Radome color |
Gray |
|
Mounting way |
Pole-holding |
|
Mounting hardware(mm) |
￠35-￠50 |
