| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-5800-14A |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 5725-5850 | Bandwidth（MHz）: | 125 |
|---|---|---|---|
| Gain（dBi）: | 14 | Half-power Beam Width（°）: | H：30 V：30 |
| VSWR: | ≤1.5 | Polarization: | Vertical |
| Lightning Protection: | DC Ground | Input Connector Type: | SMA Male Or Requested |
| High Light: | wifi antenna,wifi patch panel antenna,wifi direct antenna |
||
5.8GHz WiFi Panel Antenna
Factory price
Superior performance
Mounting kits included
Waterproof heavy-duty ABS redome
5725-5850MHz Directional Wall Mount Antenna
AMXW-5800-14A
Feature:
High gain
Strong anti-interference ability
Good defense system
Full day working
Exquisite appearance
Optimized dimension
Application:
5.8 GHz WLAN system
5.8 GHz ISMband
Public wireless hot spot coverage
|
AMXW-5800-14A Electrical Specifications |
|
|
Frequency range(MHz) |
5725-5850 |
|
Bandwidth(MHz) |
125 |
|
Gain(dBi) |
14 |
|
Half-power beam width(°) |
H:30 V:30 |
|
Front-to-back ratio(dB) |
≥27 |
|
VSWR |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical |
|
Maximum input power(W) |
50 |
|
Lightning protection |
DC Ground |
|
Input connector type |
SMA Male or Requested |
|
Mechanical Specifications |
|
|
Dimensions-mm (Height/Width/Depth) |
140*120*25 |
|
Antenna weight(kg) |
0.3 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Radome material |
ABS |
|
Radome color |
white |
|
Mounting hardware(mm) |
￠35～￠50 |
