| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-2458VH-D1817L65 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 2400～2500 And 5725～5850 | Polarization: | Vertical And Horizontal |
|---|---|---|---|
| Gain（dBi）: | 18 And 17 | Lightning Protection: | DC Ground |
| Input Connector Type: | 2×N Female | ||
| High Light: | wireless antenna,mobile antenna,dual band antenna |
||
2400-5850MHz Directional Panel Antenna
AMXP-2458VH-D1817L65
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
2.4 GHz WLAN system
2.4GHz ISM band
Wi-Fi system
5.8 GHz WLAN system
5.8 GHz ISM band
AMXP-2458VH-D1817L65 Electrical Specifications | ||
Frequency range(MHz) | 2400～2500 | 5725～5850 |
Polarization | Vertical and horizontal | |
Gain(dBi) | 18 | 17 |
half-power beam width(0°) | H:65 V:7 | H:65 V:7 |
Front-to-back ratio(dB) | ≥25 | ≥25 |
Input Impedance(Ω) | 50 | |
Isolation between ports(dB) | ≥28 | |
Cross-polar ratio(dB) | ≥15@0º ≥10@+/-60º | |
Sidelobe suppression for first sidelobe above horizon(dB) | 15 | |
VSWR | ≤1.5 | ≤1.5 |
Maximum input power(W) | 200 | 100 |
Lightning protection | DC Ground | |
Mechanical Specifications | ||
Input connector type | 2×N Female | |
Dimensions-mm (Height/Width/Depth) | 1350*114*54 | |
Packing size(mm) | 1400*130*110 | |
Antenna weight(kg) | 6.8 | |
Radome material | UPVC | |
Radome color | Gray | |
Mechanical tilt(°) | 0～10 | |
Operating temperature(°c) | -40～60 | |
Rated Wind Velocity(m/s) | 60 | |
Mounting hardware(mm) | ￠35～￠75 | |
