5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna

5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna

    • 5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna
    • 5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna
    • 5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna
    • 5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna
    • 5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna
  • 5725-5850MHz 2x18dBi Directional Panel Antenna 5.8g WLAN antenna

    Product Details:

    Place of Origin: Shenzhen, China.
    Brand Name: AMEISON
    Certification: RoHS and REACH Compliant by Exemption
    Model Number: AMXP-5800VH-D18L65

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs per item
    Price: FOB SHENZHEN
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging)
    Delivery Time: 10 days
    Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
    Supply Ability: 80,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 5725~5850 Polarization: Vertical And Horizontal
    Gain(dBi): 2×17.5 Input Impedance(Ω): 50
    VSWR: ≤1.5 Maximum Input Power(W): 200
    Lightning Protection: DC Ground Input Connector Type: 2-N Female
    Mounting Hardware(mm): ¢35~¢75

    5725-5850MHz Directional Panel Antenna

    AMXP-5800VH-D18L65

    Feature:

    High gain

    Full day working

    Optimized dimension

    Dual polarization

    Application:

    5.8 GHz WLAN system

    5.8 GHz ISM band

    Public wireless hot spot coverage

    AMXP-5800VH-D18L65

    Electrical Specifications

    Frequency range(MHz)

    5725~5850

    Polarization

    Vertical and Horizontal

    Gain(dBi)

    2×17.5

    half-power beam width(°)

    H:65 V:7

    Front-to-back ratio(dB)

    ≥25

    Input Impedance(Ω)

    50

    VSWR

    ≤1.5

    Isolation between ports

    ≥28dB

    Cross-polar ratio

    ≥15dB@0º ≥10dB@+/-60º

    Sidelobe suppression for first sidelobe above horizon

    15 dB

    Maximum input power(W)

    200

    Lightning protection

    DC Ground

    Mechanical Specifications

    Input connector type

    2-N Female

    Dimensions-mm (Height/Width/Depth)

    580*114*54

    Packing size(mm)

    620*155*145

    Antenna weight (kg)

    3.0

    Radome material

    UPVC

    Radome color

    Gray

    Mechanical tilt(°)

    0~10

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Mounting hardware(mm)

    ¢35~¢75
