| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-3338S-D13L120 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range: | 3300～3800MHz | Type: | External |
|---|---|---|---|
| Polarization: | ±45º | Gain（dBi）: | 2×13 |
| VSWR: | ≤1.5 | Maximum Input Power（W）: | 200 |
| Lightning Protection: | DC Ground | Input Connector Type: | 2-N Female |
| Mounting Hardware（mm）: | ￠35～￠75 | ||
| Highlight: | wireless antenna,wifi antenna,wimax antenna |
||
3300-3800MHz Directional Panel Antenna
AMXP-3338S-D13L120
Feature:
High gain
Full day working
Optimized dimension
Dual polarization
Application:
3.3G～3.8G wireless access coverage
|
AMXP-3338S-D13L120 Electrical Specifications |
|
|
Frequency range(MHz) |
3300～3800 |
|
Polarization |
±45º |
|
Gain(dBi) |
2×13 |
|
Half-power beam width(°) |
H:120 V:14 |
|
Front-to-back ratio(dB) |
≥18 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Isolation between ports |
≥28dB |
|
Cross-polar ratio |
≥15dB@0º ≥10dB@+/-60º |
|
Sidelobe suppression for first sidelobe above horizon |
15 dB |
|
Maximum input power(W) |
200 |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
2-N Female |
|
Dimensions-mm (Height/Width/Depth) |
410*114*54 |
|
Packing size(mm) |
450*130*110 |
|
Antenna weight (kg) |
0.9 |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt(°) |
0～10 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Mounting hardware(mm) |
￠35～￠75 |
