Place of Origin: | Shenzhen, China. |
Brand Name: | AMEISON |
Certification: | RoHS and REACH Compliant by Exemption |
Model Number: | AMXP-2327V-D17L90 |
Minimum Order Quantity: | 500 pcs per item |
---|---|
Price: | FOB SHENZHEN |
Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
Delivery Time: | 10 days |
Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
Supply Ability: | 80,000 Pieces per Month |
Frequency Range(MHz): | 2300~2700 | Polarization: | Vertical |
---|---|---|---|
Gain(dBi): | 16.5 | Input Impedance(Ω): | 50 |
VSWR: | ≤1.5 | Maximum Input Power(W): | 200 |
Lightning Protection: | DC Ground | Input Connector Type: | N Female |
Highlight: | wifi antenna,antenna,antennas for communications |
2300-2700MHz Directional Panel Antenna
AMXP-2327V-D17L90
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
2.3/2.7 GHz WLAN system
2.3/2.7 GHz ISM band
public wireless hot spot coverage
Wi-Fi system
AMXP-2327V-D17L90 Electrical Specifications |
|
Frequency range(MHz) |
2300~2700 |
Polarization |
Vertical |
Gain(dBi) |
16.5 |
Half-power beam width(°) |
H:90 V:7 |
Front-to-back ratio(dB) |
≥23 |
Input Impedance(Ω) |
50 |
VSWR |
≤1.5 |
Sidelobe suppression for first sidelobe above horizon |
15 dB |
Maximum input power(W) |
200 |
Lightning protection |
DC Ground |
Mechanical Specifications |
|
Input connector type |
N Female |
Dimensions-mm (Height/Width/Depth) |
1000*114*54 |
Packing size(mm) |
1080*155*145 |
Antenna weight (kg) |
6 |
Radome material |
UPVC |
Radome color |
Gray |
Mechanical tilt(°) |
0~10 |
Operating temperature:(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Mounting hardware(mm) |
¢35~¢75 |
