| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-1722V-D14L90 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range: | 1710～2170MHz | Type: | External |
|---|---|---|---|
| Polarization: | Vertical | Gain（dBi）: | 14 |
| Half-power Beam Width（°）: | H:90 V:14 | Front-to-back Ratio（dB）: | ≥23 |
| Input Impedance（Ω）: | 50 | VSWR: | ≤1.5 |
| Maximum Input Power（W）: | 200 | Lightning Protection: | DC Ground |
| Input Connector Type: | N Female | ||
| Highlight: | 3g antenna,wifi antenna outdoor,antenna 3g |
||
1710-2170MHz Directional Panel Antenna
AMXP-1722V-D14L90
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
DCS,PCS,3G system
Wireless communication and data transmission system
|
AMXP-1722V-D14L90 Electrical Specifications |
|
|
Frequency range(MHz) |
1710～2170 |
|
Polarization |
Vertical |
|
Gain(dBi) |
14 |
|
half-power beam width(°) |
H:90 V:14 |
|
Front-to-back ratio(dB) |
≥23 |
|
Input Impedance(Ω) |
50 |
|
VSWR |
≤1.5 |
|
Sidelobe suppression for first sidelobe above horizon |
15 dB |
|
Maximum input power(W) |
200 |
|
Lightning protection |
DC Ground |
|
Mechanical Specifications |
|
|
Input connector type |
N Female |
|
Dimensions-mm (Height/Width/Depth) |
660*175*80 |
|
Packing size(mm) |
690*200*150 |
|
Antenna weight (kg) |
4.5 |
|
Radome material |
UPVC |
|
Radome color |
Gray |
|
Mechanical tilt(°) |
0～10 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Mounting hardware(mm) |
￠35～￠75 |
