| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXP-8025H-D1012L65 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range(MHz): | 806～960 And 1710～2500 | Polarization: | Horizontal |
|---|---|---|---|
| Gain（dBi）: | 10 And 12 | Lightning Protection: | DC Ground |
| Input Connector Type: | N Female | ||
| Highlight: | wireless wlan antenna,wlan antenna,wlan booster |
||
806-2500MHz Directional Panel Antenna
AMXP-8025H-D1012L65
Feature:
High gain
Full day working
Optimized dimension
Vertical or horizontal
Application:
CDMA/GSM/PCS/3G/WLAN system
Wireless communication and data transmission system
AMXP-8025H-D1012L65 Electrical Specifications | ||
Frequency range | 806～960 | 1710～2500 |
Polarization | Horizontal | |
Gain(dBi) | 10 | 12 |
half-power beam width(0°) | H:65 V:50 | H:65 V:30 |
Front-to-back ratio(dB) | ≥25 | ≥25 |
Input Impedance(Ω) | 50 | |
VSWR | ≤1.5 | ≤1.5 |
Maximum input power(W) | 400 | 200 |
Lightning protection | DC Ground | |
Mechanical Specifications | ||
Input connector type | N Female | |
Dimensions-mm (Height/Width/Depth) | 660*280*80 | |
Packing size(mm) | 700*320*160 | |
Antenna weight (kg) | 6 | |
Radome material | UPVC | |
Radome color | Gray | |
Mechanical tilt(°) | 0～10 | |
Operating temperature(°c) | -40～60 | |
Rated Wind Velocity(m/s) | 60 | |
Mounting hardware(mm) | ￠35～￠90 | |
