5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna

5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna

    • 5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna
    • 5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna
    • 5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna
    • 5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna
    • 5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna
  • 5725-5850MHz 12dBi Omnidirectional Fiberglass Antenna 5.8g WLAN antenna

    Product Details:

    Place of Origin: Shenzhen, China.
    Brand Name: AMEISON
    Certification: RoHS and REACH Compliant by Exemption
    Model Number: AMXF-5800-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs per item
    Price: FOB SHENZHEN
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging)
    Delivery Time: 10 days
    Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
    Supply Ability: 80,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 5725~5850 Bandwidth(MHz): 125
    Gain(dBi): 12 VSWR: ≤1.5
    Polarization: Vertical Lightning Protection: DC Ground
    Input Connector Type: N Female Or Requested Mounting Way: Pole-holding

    5.8 GHz Omni fiberglass antenna

    Factory price

    All weather operation

    Included dual U-bolt mast mounting kit

    5725-5850MHz Omnidirectional Fiberglass Antenna

    AMXF-5800-12

    Feature:

    Exquisite appearance

    Good impact resistance

    Waterproofing and anticorrosion ability

    Full day working

    Optimized dimension

    High gain

    Low standing wave

    Strong anti-interference ability

    Application:

    5.8GHz system

    Point-to-multipoint system

    AMXF-5800-12

    Electrical Specifications

    Frequency range(MHz)

    5725~5850

    Bandwidth(MHz)

    125

    Gain(dBi)

    12

    Half-power beam width(°)

    H:360 V:6

    VSWR

    ≤1.5

    Input Impedance(Ω)

    50

    Polarization

    Vertical

    Maximum input power(W)

    100

    Lightning protection

    DC Ground

    Input connector type

    N Female or Requested

    Mechanical Specifications

    Dimensions (mm)

    Φ20*580

    Antenna weight(kg)

    0.34

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Radome color

    Gray

    Mounting way

    Pole-holding

    Mounting hardware(mm)

    ¢35-¢50
