2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna

2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna

    • 2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna
    • 2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna
    • 2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna
    • 2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna
    • 2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna
  • 2400-5850MHz Directional Panel Antenna 2.4g antenna 5.8g antenna wlan wifi antenna

    Product Details:

    Place of Origin: Shenzhen, China.
    Brand Name: AMEISON
    Certification: RoHS and REACH Compliant by Exemption
    Model Number: AMXP-2458VH-D1716L90

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs per item
    Price: FOB SHENZHEN
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging)
    Delivery Time: 10 days
    Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
    Supply Ability: 80,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 2400~2500 And 5725~5850 Polarization: Vertical And Horizontal
    Gain(dBi): 17 And 16 Lightning Protection: DC Ground
    Input Connector Type: 2×N Female

    2400-5850MHz Directional Panel Antenna
    AMXP-2458VH-D1716L90
    Feature:
    High gain
    Full day working
    Optimized dimension
    Vertical or horizontal
    Application:
    2.4 GHz WLAN system
    2.4GHz ISM band
    Wi-Fi system
    5.8 GHz WLAN system
    5.8 GHz ISM band

    AMXP-2458VH-D1716L90

    Electrical Specifications

    Frequency range(MHz)

    2400~2500

    5725~5850

    Polarization

    Vertical and horizontal

    Gain(dBi)

    17

    16

    half-power beam width(0°)

    H:90 V:7

    H:90 V:7

    Front-to-back ratio(dB)

    ≥23

    ≥23

    Input Impedance(Ω)

    50

    Isolation between ports(dB)

    ≥28

    Cross-polar ratio(dB)

    ≥15@0º ≥10@+/-60º

    Sidelobe suppression for first sidelobe above horizon(dB)

    15

    VSWR

    ≤1.5

    ≤1.5

    Maximum input power(W)

    200

    100

    Lightning protection

    DC Ground

    Mechanical Specifications

    Input connector type

    2×N Female

    Dimensions-mm (Height/Width/Depth)

    1350*114*54

    Packing size(mm)

    1400*130*110

    Antenna weight(kg)

    6.8

    Radome material

    UPVC

    Radome color

    Gray

    Mechanical tilt(°)

    0~10

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Mounting hardware(mm)

    ¢35~¢75
