1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna

1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna

    • 1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna
    • 1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna
    • 1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna
    • 1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna
    • 1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna
  • 1420-1530MHz 17dBi Directional Panel Antenna Wireless antenna

    Product Details:

    Place of Origin: Shenzhen, China.
    Brand Name: AMEISON
    Certification: RoHS and REACH Compliant by Exemption
    Model Number: AMXP-1415S-D17L65X

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs per item
    Price: FOB SHENZHEN
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging)
    Delivery Time: 10 days
    Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
    Supply Ability: 80,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range: 1420~1530 Polarization: ±45º
    Gain(dBi): 17 VSWR: ≤1.5
    Maximum Input Power(W): 200 Lightning Protection: DC Ground
    Input Connector Type: 4-7/16DIN Female Mounting Hardware(mm): ¢35~¢90

    1420-1530MHz Directional Panel Antenna

    AMXP-1415S-D17L65X

    Feature:

    High gain

    Full day working

    Optimized dimension

    Dual polarization

    Application:

    1420-1530 MHz Wireless communication anddata transmission system

    AMXP-1415S-D17L65X

    Electrical Specifications

    Frequency range

    1420~1530

    Polarization

    ±45º

    Gain(dBi)

    17

    half-power beam width(0°)

    H:65 V:7

    Front-to-back ratio(dB)

    ≥25

    Input Impedance(Ω)

    50

    Isolation between ports

    ≥28dB

    Cross-polar ratio

    ≥15dB@0º ≥10dB@+/-60º

    Sidelobe suppression for first sidelobe above horizon

    15 dB

    VSWR

    ≤1.5

    Maximum input power(W)

    200

    Lightning protection

    DC Ground

    Mechanical Specifications

    Input connector type

    4-7/16DIN Female

    Dimensions-mm (Height/Width/Depth)

    1520*280*80

    Packing size(mm)

    1570*320*160

    Antenna weight (kg)

    11

    Radome material

    UPVC

    Radome color

    Gray

    Mechanical tilt(°)

    0~10

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Mounting hardware(mm)

    ¢35~¢90
