| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXF-433-5 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency Range（MHz）: | 433±5 | Bandwidth（MHz）: | 10 |
|---|---|---|---|
| Gain（dBi）: | 5 | Half-power Beam Width（°）: | H:360 V:30 |
| VSWR: | ≤1.5 | Polarization: | Vertical |
| Lightning Protection: | DC Ground | Input Connector Type: | N Female Or Requested |
| High Light: | wifi antenna,omni antenna,omnidirectional antenna |
||
428-438 Mhz Omni fiberglass antenna
Factory price
Lightweight fiberglass radome
Provided wifh dual u-bolt mast mounting kit
433MHz Omnidirectional Fiberglass Antenna
AMXF-433-5
Feature:
Exquisite appearance
Good impact resistance
Waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain
Low standing wave
Strong anti-interference ability
Application:
433 MHz system
Point-to-multipoint system
|
AMXF-433-5 Electrical Specifications |
|
|
Frequency range(MHz) |
433±5 |
|
Bandwidth(MHz) |
10 |
|
Gain(dBi) |
5 |
|
Half-power beam width(°) |
H:360 V:30 |
|
VSWR |
≤1.5 |
|
Input Impedance(Ω) |
50 |
|
Polarization |
Vertical |
|
Maximum input power(W) |
100 |
|
Lightning protection |
DC Ground |
|
Input connector type |
N Female or Requested |
|
Mechanical Specifications |
|
|
Dimensions (mm) |
Φ20*1170 |
|
Antenna weight(kg) |
0.56 |
|
Operating temperature(°c) |
-40～60 |
|
Rated Wind Velocity(m/s) |
60 |
|
Radome color |
Gray |
|
Mounting way |
Pole-holding |
|
Mounting hardware(mm) |
￠35-￠50 |
