| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-2425VH-D15L65 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequence Range: | 2400-2500 MHz | Polarization: | Vertial & Horizantal |
|---|---|---|---|
| Gain (dBi): | 2x15 | Half-power Beam Width（°）: | H:65 V:14 |
| VSWR: | ≤1.5 | Lightning Protection: | DC Ground |
| High Light: | antenna 2.4ghz,antenna,antenna wifi |
||
2.4 GHz Flat Panel Antenna
Factory price
All weather operation
Included Mounting bracket
Heavy Duty UV-Resistant Radome
2.4 GHz 15 dBi Dual Polarized Flat Panel Antenna
Model No.: AMXW-2425VH-D15L65
The Amesion AMXW-2425VH-D15L65 Flat Panel Antenna combines vertical and horizontal polarization with high gain in a single enclosure. It is a professional quality antenna designed primarily for MIMO point-to-multipoint and point-to-point applications in the 2.4 GHz frequency bands. The unit can be used with APs and Routers with 1 or 2 antenna ports.
Rugged and Weatherproof
This antenna features a heavy-duty UV-resistant plastic radome for all-weather operation. The AMXW-2425VH-D15L65 antenna is supplied with a stainless steel tilt and swivel mast mount kit. This allows quick installation at various degrees of up/down tilt for easy alignment.
For additional information and complete specifications, Please check the data sheet below.
Features:
Vertical and horizontal polarization
Dual polarity feed system - (2) N-Female connectors
UV-resistant radome for all-weather operation
High gain operation
Includes tilt and swivel mast mounting
Applications:
IEEE 802.11b/g/n Wireless LAN
2.4 GHz ISM band
MIMO applications
Wireless Internet Provider "Cell" sites
Public wireless hotspot
AMXW-2425VH-D15L65 Electrical Specifications
Frequency range(MHz) 2400~2500
Polarization Vertical and Horizontal
Gain(dBi) 2×15
Half-power beam width(°) H:65 V:14
Front-to-back ratio(dB) ≥25
Input Impedance(Ω) 50
VSWR ≤1.5
Isolation between ports ≥28dB
Cross-polar ratio ≥15dB@0º ≥10dB@+/-60º
Sidelobe suppression for first sidelobe above horizon 15 dB
Maximum input power(W) 200
Lightning protection DC Ground
Mechanical Specifications
Input connector type 2-N Female
Dimensions-mm (Height/Width/Depth) 405*140*28
Packing size(mm) 440*160*90
Antenna weight (kg) 0.52
Radome material ABS
Radome color White
Mechanical tilt(°) 0~10
Operating temperature(°c) -40~60
Rated Wind Velocity(m/s) 60
Mounting hardware(mm) Φ30~Φ50
