3.5g WIMAX UMTS antenna 3400-3600MHz 12dBi Omnidirectional Fiberglass Antenna

3.5g WIMAX UMTS antenna 3400-3600MHz 12dBi Omnidirectional Fiberglass Antenna

    • 3.5g WIMAX UMTS antenna 3400-3600MHz 12dBi Omnidirectional Fiberglass Antenna
    • 3.5g WIMAX UMTS antenna 3400-3600MHz 12dBi Omnidirectional Fiberglass Antenna
    • 3.5g WIMAX UMTS antenna 3400-3600MHz 12dBi Omnidirectional Fiberglass Antenna
  • 3.5g WIMAX UMTS antenna 3400-3600MHz 12dBi Omnidirectional Fiberglass Antenna

    Product Details:

    Place of Origin: Shenzhen, China.
    Brand Name: AMEISON
    Certification: RoHS and REACH Compliant by Exemption
    Model Number: AMXF-3500-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 500 pcs per item
    Price: FOB SHENZHEN
    Packaging Details: bubble PP bag or EPE/inner box/master carton(safe export packaging)
    Delivery Time: 10 days
    Payment Terms: L/C,T/T,Western Union,MoneyGram,PayPal
    Supply Ability: 80,000 Pieces per Month
    Contact Now
    Detailed Product Description
    Frequency Range(MHz): 3400~3600 Gain(dBi): 12
    VSWR: ≤1.5 Polarization: Vertical
    Lightning Protection: DC Ground Input Connector Type: N Female Or Requested
    Mounting Way: Pole-holding

    UMTS antenna:

    3.5 GHz WIMAX System

    Repeater & Base station system

    Strong supply capacity

    Direct factory product

    Good appearance

    Durable

    Corrosion resistance

    Full day for working

    Waterproof

    Optimized dimension

    High Gain

    Lower VSWR

    Strongly Anti-interference

    Application:

    Point to Multipoint system

    Wireless data 3.5GHz transmission system

    AMXF-3500-12

    Electrical Specifications

    Frequency range(MHz)

    3400~3600

    Bandwidth(MHz)

    200

    Gain(dBi)

    12

    Half-power beam width(°)

    H:360 V:6

    VSWR

    ≤1.5

    Input Impedance(Ω)

    50

    Polarization

    Vertical

    Maximum input power(W)

    100

    Lightning protection

    DC Ground

    Input connector type

    N Female or Requested

    Mechanical Specifications

    Dimensions (mm)

    Φ20*830

    Antenna weight(kg)

    0.4

    Operating temperature(°c)

    -40~60

    Rated Wind Velocity(m/s)

    60

    Radome color

    Gray

    Mounting way

    Pole-holding

    Mounting hardware(mm)

    ¢35-¢50
