| Place of Origin: | Shenzhen, China. |
| Brand Name: | AMEISON |
| Certification: | RoHS and REACH Compliant by Exemption |
| Model Number: | AMXW-2300-2700-10 |
| Minimum Order Quantity: | 500 pcs per item |
|---|---|
| Price: | FOB SHENZHEN |
| Packaging Details: | bubble PP bag or EPE/inner box/master carton(safe export packaging) |
| Delivery Time: | 10 days |
| Payment Terms: | L/C,T/T,Western Union,MoneyGram,PayPal |
| Supply Ability: | 80,000 Pieces per Month |
| Frequency: | 2300-2700MHz | Gain: | 10dBi |
|---|---|---|---|
| Type: | Extenal | Dimension: | 140*120*40 Mm |
| Weight: | 285g | ||
| High Light: | antenna mount,mobile antenna mount,antenna |
||
WIFI receiver antenna:
2.4GHZ WLAN WIFI System
10dBi or higher
Direct manufacturers
|
Model NO |
AMXW-2300-2700-10 |
|
Electric Spec |
|
|
Frequency rang-MHz |
2300-2700 |
|
Bandwidth -MHz |
400 |
|
Gain -dBi |
10 |
|
beam width -° |
H:60 V:45 |
|
VSWR |
≤1.5 |
|
Input Impedance-Ω |
50 |
|
Polarization |
Vertical |
|
Max power -W |
50 |
|
Lightning protection |
DC ground |
|
Connector model |
MA female or others |
|
Mechanical Specification |
|
|
Size -mm |
140*120*40 |
|
Antenna weight-kg |
0.285 |
|
Working Temperature -°c |
-40~60 |
|
Rated Wind Velocity-m/s |
60 |
|
Radome color |
white |
|
Mounting way |
mount on the wall or hold in the pole |
